Multi-Circuit IOT Energy Meter ADW210

Update time：2021-01-12

● Mearsure Up to 4 circuit 3 phase
● Mearsure all electric parameters
● Split core open loop CTs
● External function module, such as MK(switching inputs and outputs),
MTL(temperature measurement and leakage current measurement),
AWT100(wireless communication)

Information

Download

General

ADW2XX series rail type multi-loop power meters are mainly used for measuring the full electric parameters of multiple three-phase circuits,Up to four three-phase loop current inputs can be connected simultaneously.It Can measure voltage and current, power, power factor, phase angle, unbalance, harmonic and other parameters.

Features

● Mearsure Up to 4 circuit 3 phase
● Mearsure all electric parameters
● Split core open loop CTs
● External function module, such as MK(switching inputs and outputs),

MTL(temperature measurement and leakage current measurement),

AWT100(wireless communication)

Naming Rule

Function

	AccuracyActive power: Class 1Reactive power: Class 2FrequencyRange: 50 - 60HzPulse outputActive pulse output and reactive pulse outputConsumption<0.5VA(Single phase)
Dimension (LWH)Panel size (L×W): 7297.736 mmInstallation: Din 35mmWirelessDownlink RS485 , Upload Ethenet, 4G, LORA, LORAWAN , LORA, WifiStarting current: 4‰lb

Technical Parameters

Auxiliary power		AC/DC 85～265V; Consumption≤10VA;
Input	Frequency	45～65Hz;
	Voltage	AC 3×220V/380V; Overload: 1.2 times of rated value (continuous);2 times of rated value / 1s; Power consumption: ≤ 0.5VA;
	Current	AC 5A、100A、400A、600A;(External opening transformer); Power consumption: ≤ 0.5VA;Overload: 1.2 times of rated value (continuous); 10 times of rated value / 1s;
Measurement accuracy		Frequency 0.05Hz, voltage、current Class 0.5; 2-31st harmonic accuracy: ± 1%;Active electric energy level 1, reactive electric energy level 2;
Features	Pulse output	Output mode: optocoupler pulse with open collector;
	Communication	RS485、Modbus-RTU; Baud rate 1200～38400;
	Switching Input	Dry contact input、Built in power supply;
	Switching Output	Output mode: Relay normally open contact output; contact rating: AC 250V/3A DC 30V/3A;

Front Panel

① U / Pulse / DO / DI / Communication / Auxiliary Power Supply② Brand③ Panel④ Model Number⑤ CH1, CH2, CH3, CH4 for current / extension module interface⑥ Button⑦ Infrared Status⑧ Pulse Output Light

Optional Module

External Module (MTL)12 External NTC Temp. Measurement4 Channels Residual Current Measurement
