● Lora communication on 470MHz
● Rated I: 1.5(6)A,20(100)A,40(200)A,80(400)A,120(600)A
● Rated U: 3×220/380V,3*380V,3*57.7/100V
● kWh Class 1
● DIN 35 mm
General
AEW 100 is a multifunction power meter. There are functions like RS485 communication and Lora communication on 470MHz. Withbuild-in MODBUS-RTU protocol, AEW100 can match most of the system integrate requirement. AEW100 has the advantage of higher accuracy, more compact and easy installing.
The most attractive parts of this products is it can operate with power on, really save time and cost. But operaters need to wear insulation gloves.
When it is not convenient to get voltage, this meter can get voltage by piecing or by magnetic conneciton
Features
● RS485 and Infrared communication
● Lora communication on 470MHz
● Rated I: 1.5(6)A,20(100)A,40(200)A,80(400)A,120(600)A
● Rated U: 3×220/380V,3*380V,3*57.7/100V
● kWh Class 1
● DIN 35 mm
Technical Parameters
Type
Dimension
Wiring
Typical Connection
Photo on-site
Hanging type & rail type
