● Support data acquisition of the serial port MODBUS RTU protocol.
● Support for data acquisition of up to 30 MODBUS RTU devices.
● Support the acquisition of 5 register address fields for each MODBUS device.
● Support triggering alarms by presetting alarm addresses and alarm values for each MODBUS address range.
● Support server MODBUS or LORA unvarnished transmission communication.
● Support to connect the data center by fixed IP and dynamic domain name resolution.
Smart gateway connection with lora/RS485, 4g energy meter. AF-GSM300-HW868 dowload is lora and rs485 communication , need to be used with AEW100 energy meters, upload is 4G,follow MQTT protocol,specially desinged for overseas market,can be easily connected to RTU,PLC,computer or other equipment.
Features
1. Support serial MODBUS RTU protocol data acquisition, and communicate with Acrel server through Acrel platform protocol.
2. Support data acquisition of up to 30 MODBUS RTU devices.
3. It supports the collection of address fields of 5 registers for each MODBUS device, and the address range of each register is not more than 64.
4. Support to trigger the alarm for each MODBUS address range with preset alarm address and alarm value.At present, there are up to 14 alarm addresses in each address field.
5. Support the server MODBUS or LORA through communication.
6. Support fixed IP and dynamic domain name resolution to connect data center.
Technical Parameters
Panel
Typical Connection
