ANet-1E2S1-4G is a universal intelligent communication management machine developed by Acrel  Electric Co., Ltd., which has Full-Netcom wireless networking function. It is suitable for the national public  authorities, enterprises and institutions, public institutions, residential commercial buildings, hotels and  restaurants, etc. It can meet the requirements of water, electricity, gas, oil, cooling capacity, heat and other  forms of consumption and energy consumption measurement data collection.

Features

● Double wide voltage (DC / AC 85V ~ 265V) reverse connection protection

● Support 2G/3G/4G

● Support local and remote configuration maintenance and real-time data monitoring

● Max.64 device data collection,support MODBUS-RTU or MODBUS-TCP device

● Support breakpoint continuation,Xml, Json for data transmit

● Support standard 8GB SD card (Max. 32GB)

● Multiple alarm setting for each device

Characteristics

Communication：Downlink: 2* RS485 Uplink: 4G

Protocol: ModbusRtu, ModbusTCP, OPC UA,

Auxiliary power supply：AC/DC 220V (85-265V)

Function

Technical Parameter

Panel Instruction

Typical Connection
