Cloud Platform for Power IOT
Update time:2021-01-22
  • Cloud Platform for Power IOT
Cloud Platform for Power IOT for Substation,building,telecommunication base station,industrial energy consumption,intelligent lighthouse,operation and maintenance of power.
Contact us
Information

Cloud Platform for Power IOT

Application



Substation,building,telecommunication base station,industrial energy consumption,intelligent lighthouse,operation and maintenance of power.

Structure



Our advantages




By using IoT gateways or wireless energy meter, can we remotely receive and monitor all the data collected by the energy meter through IoT Energy Management System no matter how long the distance between each monitoring area is.


According to the energy reports generated by IoT Energy Management System, we can recognize which part of the circuits, in other words, which areas of company and production line are having potential wasting of power so that we can set a appropriate energy saving plans to save your cost.


The malfunction of production lines and machines are always happened while with abnormal electrical data like over current, over voltage and etc. By using IoT Energy Management System with fault alarm for such abnormal parameters, can we detect the malfunction of circuits in times and cut the loss to minimum.


We have 3-months free trial for using IoT Energy Management System and will provide full technical support to ensure our IoT devices (Smart energy meters and IoT gateways) can be well adjusted to the system and will get the most parts of adjustment done in the factory default setting.


Main Functions



1) Alarm Analysis



Cloud Platform for Power IOT234.png



2) Energy situation



Cloud Platform for Power IOT261.png





3) Details of electrical parameters



Cloud Platform for Power IOT303.png





4) Equipment status



Cloud Platform for Power IOT331.png


5) App






Product Selection


Product NameProduct imageFunction


ADW210 IOT Multi-circuit Energy Meter







 Measurement: 4 circuits 3 phase voltage,current,power,power factor ,etc.
 Max demand
● Communication:RS485 or LoRa




ADW300 Wirless Energy Meter


 Measurement:3 Phase voltage,current,power,power factor,etc.
 Accuracy:1
 Max demand
● Communication:RS485,LoRa,4G,NB or 2G






ADL200 Single Phase Energy Meter20220224162918194.jpg
●Accuracy: kWh: Class 0.5s
●Frequency: 45~65 Hz
●12 digits LCD display U, I, P, Q, PF, kWh
●Range of measuring: 000000.00~99999999 kWh
●Communication:RS485, Modbus-RTU
ADL400 Three Phase Energy Meter20220224163106418.jpg
●Accuracy: kWh: Class 0.5s
●Frequency: 45~65 Hz
●12 digits LCD display U, I, P, Q, PF, kWh
●Range of measuring: 000000.00~99999999 kWh
●Communication:RS485, Modbus-RTU
AGF Multi-circuit DC Energy Monitoring Device

●With3-way switch status monitoring,collect the output empty contact status of DC 24(maximum) circuit breakers, lightning protection devices, etc.
●Range of voltage measuring: DC 0~1500V
●Communication:RS485,Modbus-RTU


ATC600 Wireless Temp. Transceiver


●Temperature Data Transmission: 240
●Communication:RS485
●Type: C: Terminal mode; Z: Relay mode


DJSF1352 DC Power Meter20220224163642120.jpg
●Accuracy: kWh: Class 1S or 0.5s, with ±12V  voltage output for hall sensor power supply
●Measurement: voltage, current, power, forward and reverse electric energy, wo-way metering
●Communication: RS485
AWT100-4GHW Gateway

/ lorawan868/ lorawan923/ lora868
● Downlink:RS485
●Uplink:4G,WiFi or Ethernet/lorawan868/lorawan923/lora868
